Description
24.3MP FX-Format CMOS Sensor
EXPEED 3 Image Processor
3.2″ 921k-Dot LCD Monitor
Full HD 1080p Video Recording at 30 fps
Multi-CAM 4800 39-Point AF Sensor
Native ISO 6400, Extended to ISO 25600
6 fps Shooting at Full Resolution
Built-In Flash with Commander Mode
Supports WU-1b Wireless Mobile Adapter
6-fps continuous shooting: FX-format quality at full-throttle speed
Thanks to the high-speed performance of the EXPEED 3 image-processing engine and an exclusive driving mechanism that drives the mirror independently, the D610 is capable of high-speed continuous shooting at approx. 6 fps*1 in FX format, for up to 100 shots*2.
*1Based on CIPA Guidelines.
*2JPEG, excluding fine/Large in FX format (max. 51 shots) and normal/Large in FX format (max. 90 shots).
Approx. 100% frame coverage: essential for accurate viewfinder framing
The D610’s optical viewfinder features approx. 100% frame coverage that enables confirmation of the entire large image area of FX format for precise composition. And approx. 0.7x* magnification allows easy viewing of all the visual elements including the viewfinder information display. The frame coverage and magnification are the same as those of the D4 and D3 series, realizing comfortable shooting.
*With a 50mm f/1.4 lens at infinity, -1.0 m-1
The Nikon FX-format CMOS sensor (35.9 x 24.0 mm) with 24.3 effective megapixels delivers stable, high image quality. EXPEED 3 image-processing engine, the same as used for the D4 and D800 series, realizes superior high-speed processing performance. The D610’s Picture Control system lets you fine-tune sharpening, contrast, saturation, hue, and various adjustments for Monochrome, etc. in both still images and movies according to your preference. The D610’s new Qc (quiet continuous) shutter-release mode reduces mirror noise while still offering up to 3 fps*, for maximum discretion.
*Based on CIPA Guidelines.
With seven focus points compatible with f/8, precise focusing is possible even when attaching a 2.0x teleconverter to telephoto lenses with a maximum aperture of f/4. Scene Recognition System recognizes the subject’s situation accurately prior to shooting and enables precise auto control. Inheriting an array of specifications and functions equivalent to those of the D4 and D800 series, the D610 combines them in a remarkably small and light camera body. SD memory card double slots compatible with high-speed SDXC and UHS-I. Time-lapse photography lets you shoot automatically at designated intervals and save as a movie to replay slow-moving activity at high speed. The D610’s built-in flash incorporates a commander function that supports Advanced Wireless Lighting.
Specification :
| Nikon Digital SLR Camera D610 | |
| Type | |
| Type | Single-lens reflex digital camera |
| Lens mount | Nikon F mount (with AF coupling and AF contacts) |
| Effective pixels | |
| Effective pixels | 24.3 million |
| Image sensor | |
| Image sensor | 35.9 x 24.0 mm CMOS sensor (Nikon FX format) |
| Total pixels | 24.7 million |
| Dust-reduction system | Image sensor cleaning, Image Dust Off reference data (optional Capture NX 2 software required) |
| Storage | |
| Image size (pixels) | FX format (36×24): 6,016 x 4,016 (L), 4,512 x 3,008 (M), 3,008 x 2,008 (S) |
| DX format (24×16): 3,936 x 2,624 (L), 2,944 x 1,968 (M), 1,968 x 1,312 (S) | |
| FX-format photographs taken in movie live view: 6,016 x 3,376 (L), 4,512 x 2,528 (M), 3,008 x 1,688 (S) | |
| DX-format photographs taken in movie live view: 3,936 x 2,224 (L), 2,944 x 1,664 (M), 1,968 x 1,112 (S) | |
| File format | NEF (RAW): 12 or 14 bit, lossless compressed or compressed |
| JPEG: JPEG-Baseline compliant with fine (approx. 1:4), normal (approx. 1:8) or basic (approx. 1:16) compression (Size priority); Optimal quality compression available | |
| NEF (RAW)+JPEG: Single photograph recorded in both NEF (RAW) and JPEG formats | |
| Picture Control System | Standard, Neutral, Vivid, Monochrome, Portrait, Landscape; selected Picture Control can be modified; storage for custom Picture Controls |
| Media | SD (Secure Digital) and UHS-I compliant SDHC and SDXC memory cards |
| Dual card slots | Slot 2 can be used for overflow or backup storage or for separate storage of copies created using NEF+JPEG; pictures can be copied between cards |
| File system | DCF (Design Rule for Camera File System) 2.0, DPOF (Digital Print Order Format), Exif (Exchangeable Image File Format for Digital Still Cameras) 2.3, PictBridge |
| Viewfinder | |
| Viewfinder | Eye-level pentaprism single-lens reflex viewfinder |
| Frame coverage | FX (36×24): Approx. 100% horizontal and 100% vertical |
| DX (24×16): Approx. 97% horizontal and 97% vertical | |
| Magnification | Approx. 0.7x (50 mm f/1.4 lens at infinity, -1.0 m-1) |
| Eyepoint | 21 mm (-1.0 m-1; from center surface of viewfinder eyepiece lens) |
| Diopter adjustment | -3 to +1 m-1 |
| Focusing screen | Type B BriteView Clear Matte Mark VIII screen with AF area brackets (framing grid can be displayed) |
| Reflex mirror | Quick return |
| Depth-of-field preview | Pressing depth-of-field preview button stops lens aperture down to value selected by user (A and M modes) or by camera (other modes) |
| Lens aperture | Instant return, electronically controlled |
| Lens | |
| Compatible lenses | Compatible with AF NIKKOR lenses, including type G,E and D lenses (some restrictions apply to PC lenses), DX lenses [using DX (24×16) image area], AI-P NIKKOR lenses, and non-CPU AI lenses (A and M modes only); IX-NIKKOR lenses, lenses for the F3AF, and non-AI lenses cannot be used |
| The electronic rangefinder can be used with lenses that have a maximum aperture of f/5.6 or faster (the electronic rangefinder supports the center 7 focus points with lenses that have a maximum aperture of f/8 or faster and the center 33 focus points with lenses that have a maximum aperture of f/6.8 or faster) | |
| Shutter | |
| Type | Electronically-controlled vertical-travel focal-plane shutter |
| Speed | 1/4,000 to 30 s in steps of 1/3 or 1/2 EV, bulb, time (requires optional ML-L3 Remote Control), X200 |
| Flash sync speed | X=1/200 s; synchronizes with shutter at 1/250 s or slower (flash range drops at speeds between 1/200 and 1/250 s) |
| Release | |
| Release modes | S (single frame), CL (continuous low speed), CH (continuous high speed), Q (quiet shutter-release), QC (quiet continuous shutter-release), |
| (self-timer), | |
| (remote control), MUP (mirror up) | |
| Frame advance rate | Approx. 1 to 5 fps (CL), approx. 6 fps (CH) or 3 fps (QC) |
| Self-timer | 2 s, 5 s, 10 s, 20 s; 1 to 9 exposures at intervals of 0.5, 1, 2 or 3 s |
| Remote release modes | Delayed remote, quick-response remote, remote mirror-up |
| Exposure | |
| Metering | TTL exposure metering using 2,016-pixel RGB sensor |
| Metering method | Matrix: 3D color matrix metering II (type G,E and D lenses); color matrix metering II (other CPU lenses); color matrix metering available with non-CPU lenses if user provides lens data |
| Center-weighted: Weight of 75% given to 12-mm circle in center of frame; diameter of circle can be changed to 8, 15 or 20 mm, or weighting can be based on average of entire frame (non-CPU lenses use 12-mm circle or average of entire frame) | |
| Spot: Meters 4-mm circle (about 1.5% of frame) centered on selected focus point (on center focus point when non-CPU lens is used) | |
| Range | Matrix or center-weighted metering: 0 to 20 EV |
| (ISO 100, f/1.4 lens, 20°C/68°F) | Spot metering: 2 to 20 EV |
| Exposure meter coupling | Combined CPU and AI |
| Exposure modes | Auto ( |
| auto; | |
| auto [flash off]), scene ( | |
| portrait, | |
| landscape, | |
| child, | |
| sports, | |
| close up, | |
| night portrait, | |
| night landscape, | |
| party/indoor, | |
| beach/snow, | |
| sunset, | |
| dusk/dawn, | |
| pet portrait, | |
| candlelight, | |
| blossom, | |
| autumn colors, | |
| food, | |
| silhouette, | |
| high key, | |
| low key), programmed auto with flexible program (P), shutter-priority auto (S), aperture-priority auto (A), manual (M), U1 (user settings 1), U2 (user settings 2) | |
| Exposure compensation | Can be adjusted by -5 to +5 EV in increments of 1/3 or 1/2 EV in P, S, A and M modes |
| Exposure bracketing | 2 to 3 frames in steps of 1/3, 1/2, 2/3, 1, 2 or 3 EV |
| Exposure lock | Luminosity locked at detected value with AE-L/AF-L button |
| ISO sensitivity | ISO 100 to 6400 in steps of 1/3 or 1/2 EV; can also be set to approx. 0.3, 0.5, 0.7 or 1 EV (ISO 50 equivalent) below ISO 100 or to approx. 0.3, 0.5, 0.7, 1 or 2 EV (ISO 25600 equivalent) above ISO 6400; auto ISO sensitivity control available |
| (Recommended Exposure Index) | |
| Active D-Lighting | Auto, Extra high, High, Normal, Low, Off |
| ADL bracketing | 2 frames using selected value for one frame or 3 frames using preset values for all frames |
| Focus | |
| Autofocus | Nikon Multi-CAM 4800 autofocus sensor module with TTL phase detection, fine-tuning, 39 focus points (including 9 cross-type sensors; the center 33 points are available at apertures slower than f/5.6 and faster than f/8, while the center 7 points are available at f/8), and AF-assist illuminator (range approx. 0.5 to 3 m/1 ft 8 in. to 9 ft 10 in.) |
| Detection range | -1 to +19 EV (ISO 100, 20°C/68°F) |
| Lens servo | Autofocus (AF): Single-servo AF (AF-S); continuous-servo AF (AF-C); auto AF-S/AF-C selection (AF-A); predictive focus tracking activated automatically according to subject status |
| Manual focus (M): Electronic rangefinder can be used | |
| Focus point | Can be selected from 39 or 11 focus points |
| AF-area modes | Single-point AF, 9-, 21- or 39-point dynamic-area AF, 3D-tracking, auto-area AF |
| Focus lock | Focus can be locked by pressing shutter-release button halfway (single-servo AF) or by pressing AE-L/AF-L button |
| Flash | |
| Guide number | Approx. 12/39, 12/39 with manual flash (m/ft, ISO 100, 20°C/68°F) |
| Flash control | TTL: i-TTL flash control using 2,016-pixel RGB sensor is available with built-in flash and SB-910, SB-900, SB-800, SB-700, SB-600, SB-400 or SB-300; i-TTL balanced fill-flash for digital SLR is used with matrix and center-weighted metering, standard i-TTL flash for digital SLR with spot metering |
| Flash modes | Auto, auto with red-eye reduction, auto slow sync, auto slow sync with red-eye reduction, fill-flash, red-eye reduction, slow sync, slow sync with red-eye reduction, rear-curtain with slow sync, rear-curtain sync, off; auto FP high-speed sync supported |
| Flash compensation | -3 to +1 EV in increments of 1/3 or 1/2 EV |
| Flash bracketing | 2 to 3 frames in steps of 1/3, 1/2, 2/3, 1, 2 or 3 EV |
| Flash-ready indicator | Lights when built-in flash or optional flash unit is fully charged; flashes after flash is fired at full output |
| Accessory shoe | ISO 518 hot-shoe with sync and data contacts and safety lock |
| Nikon Creative Lighting | Advanced Wireless Lighting supported with built-in flash, SB-910, SB-900, SB-800 or SB-700 as a master flash and SB-600 or SB-R200 as remotes, or SU-800 as commander; built-in flash can serve as master flash in commander mode; auto FP high-speed sync and modeling illumination supported with all CLS-compatible flash units except SB-400; Flash Color Information Communication and FV lock supported with all CLS-compatible flash units |
| System (CLS) | |
| Sync terminal | AS-15 Sync Terminal Adapter (available separately) |
| White balance | |
| White balance | Auto (2 types), incandescent, fluorescent (7 types), direct sunlight, flash, cloudy, shade, preset manual (up to 4 values can be stored), choose color temperature (2,500 K to 10,000 K); all with fine-tuning |
| White balance bracketing | 2 to 3 frames in steps of 1, 2 or 3 |
| Live View | |
| Modes | Live view photography (still images), movie live view (movies) |
| Lens servo | Autofocus (AF): Single-servo AF (AF-S); full-time servo AF (AF-F) |
| Manual focus (M) | |
| AF-area modes | Face-priority AF, wide-area AF, normal-area AF, subject-tracking AF |
| Autofocus | Contrast-detect AF anywhere in frame (camera selects focus point automatically when face-priority AF or subject-tracking AF is selected) |
| Movie | |
| Metering | TTL exposure metering using main image sensor |
| Metering method | Matrix |
| Frame size (pixels) | 1,920 x 1,080; 30p (progressive), 25p, 24p |
| and frame rate | 1,280 x 720; 60p, 50p, 30p, 25p |
| Actual frame rates for 60p, 50p, 30p, 25p, and 24p are 59.94, 50, 29.97, 25, and 23.976 fps respectively; options support both ? high and normal image quality | |
| File format | MOV |
| Video compression | H.264/MPEG-4 Advanced Video Coding |
| Audio recording format | Linear PCM |
| Audio recording device | Built-in monaural or external stereo microphone; sensitivity adjustable |
| Maximum length | Approx. 29 min. 59 s (20 min. depending on frame size/rate and movie quality settings) |
| Other options | Index marking, time-lapse photography |
| Monitor | |
| Monitor | Monitor 8-cm (3.2-in.), approx. 921k-dot (VGA), low-temperature polysilicon TFT LCD with approx. 170° viewing angle, approx. 100% frame coverage, and automatic monitor brightness control using ambient brightness sensor |
| Playback | |
| Playback | Full-frame and thumbnail (4, 9, 72 images or calendar) playback with playback zoom, movie playback, photo and/or movie slide shows, histogram display, highlights, photo information, GPS data display and auto image rotation |
| Interface | |
| USB | Hi-Speed USB |
| HDMI output | Type C mini-pin HDMI connector |
| Accessory terminal | Remote cord: MC-DC2 (available separately) |
| GPS unit: GP-1/GP-1A (available separately) | |
| Audio input | Stereo mini-pin jack (3.5-mm diameter; plug-in power supported) |
| Audio output | Stereo mini-pin jack (3.5-mm diameter) |
| Supported languages | |
| Supported languages | Arabic, Chinese (Simplified and Traditional), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hindi, Hungarian, Indonesian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Portugal and Brazil), Romanian, Russian, Spanish, Swedish, Thai, Turkish, Ukrainian |
| Power source | |
| Battery | One EN-EL15 Rechargeable Li-ion Battery |
| Battery pack | Optional MB-D14 Multi-Power Battery Pack with one EN-EL15 Rechargeable Li-ion Battery or six AA alkaline, Ni-MH, or lithium batteries |
| AC adapter | EH-5b AC Adapter; requires EP-5B Power Connector (available separately) |
| Tripod socket | |
| Tripod socket | 1/4 in. (ISO 1222) |
| Dimensions / weight | |
| Dimensions | Approx. 141 x 113 x 82 mm/ 5.6 x 4.4 x 3.2 in. |
| (W x H x D) | |
| Weight | Approx. 850 g/1 lb 14.0 oz with battery and memory card but without body cap; approx. 760 g/1 lb 10.8 oz (camera body only) |
| Operating environment | |
| Operating environment | Temperature: 0 to 40°C/32 to 104°F; humidity: 85% or less (no condensation) |
| Accessories | |
| Supplied accessories | EN-EL15 Rechargeable Li-ion Battery, MH-25 Battery Charger, DK-5 Eyepiece Cap, DK-21 Rubber Eyecup, UC-E15 USB Cable, AN-DC10 Camera Strap, BM-14 LCD Monitor Cover, BF-1B Body Cap, BS-1 Accessory Shoe Cover, ViewNX 2 CD-ROM |
| (may differ by country or area) | |
