Description
This ultra-wide zoom lens has a wide angle of view from 102.4 – 63.8 degrees (when Sigma mount is used) and it is exclusive to digital SLR cameras. SLD glass elements effectively compensate color aberration. Aspherical lenses provide maximum correction for distortion and various aberrations; high image quality is displayed throughout the entire zoom range. The HSM equipped models makes
fast AF speeds and quiet shooting a reality, and it is also capable of full-time manual focus. It has a minimum focusing distance of 9.4″ (24cm) at all focal lengths. It is also equipped with an integral Petal-type hood to block out extraneous light.
Ultra-wide zoom lens
10-20mm F4-5.6 EX DC HSM lens allows enjoyment of super wide-angle photography and it is a very powerful tool for indoor shooting and landscape photography with APS-C size image sensors of digital SLR cameras. Wide angle of view 102.4-63.8 degrees (for Sigma mount) offers the photographer greater freedom of expression.
Most Appropriate Coating for Digital SLR Cameras The new multi layer lens coating and lens design reduce flare and ghost, which is a common problem with digital cameras and also creates an optimum color balance through the entire zoom range.
The best possible correction of aberrations Three SLD (Special Low Dispersion) glass elements are employed for effective compensation of color aberration, which is a common problem with super-wide angle lenses. One piece of glass mold and two hybrid aspherical lenses, offer excellent
correction for distortion, as well as all types of aberration.
Inner focus system This lens incorporates an internal focusing system, which eliminates front lens rotation allowing the use of a Petal-type Hood and also minimize fluctuation of aberration caused by focusing system.
HSM (Hyper Sonic Motor)
The HSM equipped models ensure a silent, high-speed AF function as well as full-time manual focusing capability for Sigma, Canon, and Nikon-D mount lenses.
Minimum focusing distance of 9.4″ (24cm) at all focal lengths
This lens has a minimum focusing distance of 9.4″ (24cm) throughout the entire zoom range.
Specifications:
Lens Construction
14 Elements in 10 Groups
Angle of View
102.4 – 63.8 degrees
Number of Diaphragm Blades
6
Minimum Aperture
F22
Minimum Focusing Distance
24cm/9.4 in.
Maximum Magnification
1:6.7
Filter Size Diameter
77mm
Dimensions Diameter
83.5mm X Length 81mm
3.3 in. X 3.2 in.
Weight
465g/16.4 oz
