Description
Product Highlights
24.2MP DX-Format CMOS Sensor
EXPEED 4 Image Processor
No Optical Low-Pass Filter
3.2″ 1,229k-Dot LCD Monitor
Full HD 1080p Video Recording at 60 fps
Multi-CAM 3500 II DX 51-Point AF Sensor
Native ISO 25600, B&W to ISO 102400
6 fps Shooting for Up to 100 Frames
Built-In Wi-Fi Connectivity with NFC
DX NIKKOR 18-140mm f/3.5-5.6G ED VR Lens
Overview
Set your heart on the new D7200, the most advanced DSLR in Nikon’s DX range. The D7200 sets a new standard for image quality with its DX-format 24.2-megapixel CMOS sensor and EXPEED 4 image-processing engine. Its Advanced Multi-CAM 3500 II autofocus sensor module with 51 precise focus points captures super sharp images even in low light conditions. You can even film superior Full HD 1080/60p movies in 1.3x format, capturing distant subjects in a larger size. Share your images and movies instantly with the convenient built-in Wi-Fi® and NFC*1 – a first for Nikon DSLRs. The D7200 is your reliable companion, ready to take the shot wherever you go.
New 51-point AF with improved performance, even in low light
The D7200’s new Advanced Multi-CAM 3500 II autofocus sensor module offers strengthened capabilities. Superior low-noise ability at high ISO of the AF sensor realizes incredible performance in low-light situations at -3 EV (ISO 100, 20ºC/68ºF) with one central focus point and at -2 EV or below (above -3 EV) with the other 50 points. Its 51 focus points cover a wide area of the frame in DX format, and the entire frame in 1.3×, while 15 cross-type sensors in the center feature higher detection strength. All 51 points are responsive at f/5.6, while one center point is compatible with f/8, for greater focusing performance even when using teleconverters. The outstanding focusing performance, wide AF coverage and lens compatibility make it easier to capture various scenes sharply, from low-lit interiors to sports or wildlife. Normal 0 false false false EN-US JA X-NONE MicrosoftInternetExplorer4
Specifications
Type
Single-lens reflex digital camera
Lens mount
Nikon F mount, (with AF coupling and AF contacts)
Effective angle of view
Nikon DX format; focal length in 35 mm [135] format equivalent to approx. 1.5x that of lenses with FX format angle of view
Image sensor format
DX
Image sensor type
CMOS
Sensor size
23.5mm, x15.6mm
Total pixels
24.72million
Dust-reduction system
Image sensor cleaning, Image Dust Off reference data (Capture NX-D software required)
Effective pixels
24.2million
Image size (pixels)
DX (24×16) image area, (L)6000, x4000, (M)4496, x3000, (S)2992, x2000, 1.3x (18×12) image area, (L)4800, x3200, (M)3600, x2400, (S)2400, x1600, Photographs with image area of DX (24×16) taken with live view selector rotated to “movie live view” in live view, (L)6000, x3368, (M)4496, x2528, (S)2992, x1680, Photographs with image area of 1.3x (18×12) taken with live view selector rotated to “movie live view” in live view, (L)4800, x2696, (M)3600, x2024, (S)2400, x1344
File format
NEF (RAW): 12 or 14 bit, lossless compressed or compressed, JPEG: JPEG-Baseline compliant with fine (approx. 1 : 4), normal (approx. 1 : 8), or basic (approx. 1 : 16) compression (Size priority); Optimal quality compression available, NEF (RAW) + JPEG: Single photograph recorded in both NEF (RAW) and JPEG formats
Picture Control system
Standard, Neutral, Vivid, Monochrome, Portrait, Landscape, Flat, ; selected Picture Control can be modified; storage for custom Picture Controls
Media
SD, SDHC (UHS-I compliant), SDXC (UHS-I compliant)
Card slot
2 Secure Digital (SD) cards, Slot 2 can be used for overflow or backup storage or for separate storage of copies created using NEF+JPEG;
pictures can be copied between cards.
File system
DCF 2.0, DPOF, Exif 2.3, PictBridge
Viewfinder
Eye-level pentaprism single-lens reflex viewfinder
Frame coverage
DX (24×16) image area: Approx. 100% horizontal and 100% vertical, 1.3x (18×12) image area: Approx. 97% horizontal and 97% vertical
Magnification
Approx. 0.94 x (50 mm f/1.4 lens at infinity, –1.0 m{sup(-1)})
Eyepoint
19.5 mm (–1.0 m{sup(-1)}; from center surface of viewfinder eyepiece lens)
Diopter adjustment
-2 to +1 m{sup(-1)}
Focusing screen
Type B BriteView Clear Matte Mark II screen with AF area brackets (framing grid can be displayed)
Reflex mirror
Quick-return type
Depth-of-field preview
Yes, Pressing Pv button stops lens aperture down to value selected by user (A and M modes) or by camera (other modes)
Lens aperture
Instant return, electronically controlled
Compatible lenses
Compatible with AF NIKKOR lenses, including type G, E, and D lenses (some restrictions apply to PC lenses) and DX lenses, AI-P NIKKOR lenses, and non-CPU AI lenses (A and M modes only). IX NIKKOR lenses, lenses for the F3AF, and non-AI lenses can not be used. The electronic rangefinder can be used with lenses that have a maximum aperture of f/5.6 or faster (the electronic rangefinder supports the center 1 focus point with lenses that have a maximum aperture of f/8 or faster).
Type
Electronically-controlled vertical-travel focal-plane shutter
Speed
1/8000to, 30s, in steps of 1/3 or 1/2 EV, bulb, time, X250
Flash sync speed
X=, 1/250s;, synchronizes with shutter at 1/320 s or slower (flash range drops at speeds between 1/250 and 1/320 s)
Modes
S (single frame), CL (continuous low speed), CH (continuous high speed), Q (quiet shutter-release), Self-timer, MUP (mirror up)
Approximate frame advance rate
JPEG and 12-bit NEF (RAW) images recorded with DX (24×16) selected for Image area CL: 1–6 fps CH: 6 fps JPEG and 12-bit NEF (RAW) images recorded with 1.3x (18×12) selected for Image area CL: 1–6 fps CH: 7 fps 14-bit NEF (RAW) images recorded with DX (24×16) selected for Image area CL: 1–5 fps CH: 5 fps 14-bit NEF (RAW) images recorded with 1.3x (18×12) selected for Image area CL: 1–6 fps CH: 6 fps
Self-timer
2 s, 5 s, 10 s, 20 s; 1–9 exposures at intervals of 0.5, 1, 2, or 3 s
Remote control modes
Delayed remote, quick-response remote, remote mirror-up
Metering system
TTL exposure metering using 2016-pixel RGB sensor
Metering method
Matrix: 3D color matrix metering II (type G, E, and D lenses); color matrix metering II (other CPU lenses); color matrix metering available with non-CPU lenses if user provides lens data Center-weighted: Weight of approximately 75% given to 8 mm circle in center of frame. Diameter of circle can be changed to 6, 10, or 13 mm, or weighting can be based on average of entire frame (non-CPU lenses use 8-mm circle) Spot: Meters circle with diameter of about 3.5 mm (about 2.5% of frame) centered on selected focus point (on center focus point when non-CPU
lens is used)
Range
(ISO 100, f/1.4 lens, 20 {deg}C/68 {deg}F) Matrix or center-weighted metering: 0–20 EV Spot metering: 2–20 EV
Exposure meter coupling
CPU, AI
Mode
Auto modes (auto; auto (flash off)); scene modes (portrait; landscape; child; sports; close up; night portrait; night landscape; party/indoor; beach/snow; sunset; dusk/dawn; pet portrait; candlelight; blossom; autumn colors; food); special effects modes (night vision; color sketch; miniature effect; selective color; silhouette; high key; low key); programmed auto with flexible program (P); shutter-priority auto (S); aperture-priority auto (A); manual (M); U1 (user settings 1); U2 (user settings 2)
Exposure compensation
Can be adjusted by –5 to +5EV, in steps of1/3 or 1/2EV, in P, S, A, M, SCENE, and night vision modes
Exposure lock
Luminosity locked at detected value with AE-L/AF-L button
ISO sensitivity (Recommended Exposure Index)
ISO100to, 25600, in steps of1/3 or 1/2EV, In P, S, A, and M modes, can also be set to approx. 1 or 2 EV (ISO 102400 equivalent; monochrome only)
above ISO 25600; auto ISO sensitivity control available
Active D-Lighting
Auto, Extra high, High, Normal, Low, Off
Autofocus system
Nikon Advanced Multi-CAM 3500 II autofocus sensor module with TTL phase detection, fine-tuning, 51 focus points (including 15 cross-type sensors; f/8 supported by 1 sensor), and AF-assist illuminator (range approx. 0.5–3 m/1 ft 8 in.–9 ft 10 in.)
Detection range
–3 to +19 EV (ISO 100, 20 {deg}C/68 {deg}F)
Lens servo
Single-servo AF (AF-S), Continuous-servo AF (AF-C), Auto AF-S/AF-C selection (AF-A), ; predictive focus tracking activated automatically according to subject status, Manual focus (M):, Electronic rangefinder can be used
Focus point
51, Can be selected from 51 or 11 focus points
AF-area mode
Single-point AF; 9-, 21-, or 51-point dynamic-area AF, 3D-tracking, auto-area AF
Focus lock
Focus can be locked by pressing shutter-release button halfway (single-servo AF) or by pressing AE-L/AF-L button
Built-in flash
Auto, portrait, child, close up, night portrait, party/indoor, pet portrait, color sketch: Auto flash with auto pop-up P, S, A, M, food: Manual pop-up with button release
Guide number
Approx. 12/39, 12/39 with manual flash (m/ft, ISO 100, 20 {deg}C/68 {deg}F)
Control
TTL: i-TTL flash control using 2016-pixel RGB sensor is available with built-in flash; i-TTL balanced fill-flash for digital SLR is used with matrix or center-weighted metering, standard i-TTL fill-flash for digital SLR with spot metering
Mode
Auto, auto with red-eye reduction, auto slow sync, auto slow sync with red-eye reduction, fill-flash, red-eye reduction, slow sync, slow sync with red-eye reduction, rear-curtain with slow sync, rear-curtain sync, off; Auto FP High-Speed Sync supported
Flash compensation
-3 to +1 EV in steps of 1/3 or 1/2 EV
Flash-ready indicator
Lights when built-in flash or optional flash unit is fully charged; blinks after flash is fired at full output
Accessory shoe
ISO 518 hot-shoe with sync and data contacts and safety lock
Nikon Creative Lighting System (CLS)
Nikon CLS supported; commander mode option available
Sync terminal
AS-15 sync terminal adapter (available separately)
White balance
Auto (2 types), incandescent, fluorescent (7 types), direct sunlight, flash, cloudy, shade, preset manual (up to 6 values can be stored, spot white balance measurement available during live view), choose color temperature (2500 K–10,000 K), all with fine-tuning
Bracketing types
Exposure, Flash, White balance, ADL
Modes
Photo live view, Movie live view
Lens servo
Autofocus (AF): Single-servo AF (AF-S); full-time servo AF (AF-F) Manual focus (M)
AF-area mode
Face-priority AF, Wide-area AF, Normal-area AF, Subject-tracking AF
Autofocus
Contrast-detect AF anywhere in frame (camera selects focus point automatically when face-priority AF or subject-tracking AF is selected)
Metering
TTL exposure metering using main image sensor
Metering method
Matrix or center-weighted
Frame size (pixels) and frame rate
1920 x 1080; 60p (progressive), 50p, 30p, 25p, 24p 1280 x 720; 60p, 50p Actual frame rates for 60p, 50p, 30p, 25p, and 24p are 59.94, 50, 29.97, 25, and 23.976 fps respectively; options support both high and normal image quality 1920 x 1080; 60p and 50p are available only when 1.3x (18×12) is selected for Image area in the movie shooting menu
File format
MOV
Video compression
H.264/MPEG-4 Advanced Video Coding
Audio recording format
Linear PCM
Audio recording device
Built-in or external stereo microphone; sensitivity adjustable
Other options
Index marking, time-lapse photography
Monitor size
8cm (3.2–in.) diagonal
Monitor type
TFT monitor with approx. 170{deg} viewing angle, approx. 100% frame coverage, and brightness adjustment
Monitor resolution
Approx.1229k-dot, (VGA; 640 x RGBW x 480 = 1,228,800 dots)
Playback
Full-frame and thumbnail (4, 9, or 72 images or calendar) playback with playback zoom, movie playback, photo and/or movie slide shows, histogram display, highlights, photo information, location data display, and auto image rotation
USB connector
Hi-Speed USB, Connection to built-in USB port is recommended
HDMI output connector
Type C HDMI connector
Audio input
Stereo mini-pin jack (3.5mm diameter; plug-in power supported)
Audio output
Stereo mini-pin jack (3.5 mm diameter)
Accessory terminal
Wireless remote controllers: WR-1, WR-R10 (available separately) Remote cord: MC-DC2 (available separately) GPS unit: GP-1/GP-1A
(available separately)
Standards
IEEE 802.11b, IEEE 802.11g
Operating frequency
2412–2462 MHz (channels 1–11)
Range (line of sight)
Approximately 30 m/98 ft (assumes no interference; range may vary with signal strength and presence or absence of obstacles)
Data rate
54 Mbps Maximum logical data rates according to IEEE standard. Actual rates may differ.
Security
Authentication: Open system, WPA2-PSK
Wireless setup
Supports WPS
Access protocols
Infrastructure
Operation
NFC Forum Type 3 Tag
Supported languages
Arabic, Bengali, Bulgarian, Chinese (Simplified and Traditional), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hindi, Hungarian, Indonesian, Italian, Japanese, Korean, Marathi, Norwegian, Persian, Polish, Portuguese (Portugal and Brazil), Romanian, Russian, Serbian, Spanish, Swedish, Tamil, Telugu, Thai, Turkish, Ukrainian, Vietnamese
Battery
One EN-EL15 rechargeable Li-ion battery
Battery pack
Optional MB-D15 multi-power battery pack with one Nikon EN-EL15 rechargeable Li-ion battery or six AA alkaline, Ni-MH, or lithium batteries
AC adapter
EH-5b AC adapter; requires EP-5B power connector (available separately)
Tripod socket
1/4–in. (ISO 1222)
Dimensions (W x H x D)
Approx.135.5, x106.5, x76mm (5.4, x4.2, x3.0in.)
Weight
Approx.765g (1 lb 11.0 oz), with battery and memory card but without body cap; approx. 675 g (1 lb 7.9 oz; camera body only)
Operating environment
Temperature: 0 {deg}C–40 {deg}C (+32 {deg}F–104 {deg}F) Humidity: 85% or less (no condensation)
Supplied accessories
Rubber Eyecup DK-23, Body Cap BF-1B, Rechargeable Li-ion Battery EN-EL15 with terminal cover, Battery Charger MH-25a (comes with either an AC wall adapter or power cable of a type and shape that varies with the country or region of sale), Eyepiece Cap DK-5, USB Cable UC-E17, Strap AN-DC1 BK
