Description
Phottix Odin TTL Flash Trigger for Nikon Receiver Only
Quick Overview
Receiver only for the Phottix Odin TTL Flash Trigger for Nikon (Patent Pending)
Product Description
Receiver only for the Phottix Odin TTL Flash Trigger for Nikon (Patent Pending)
What’s included:
Phottix Odin Receiver
2x AA Batteries
3.5mm to PC Sync Cable
3.5mm to 3.5mm cable
6.3mm adapter
Lanyard
Instructions CD
Technical Specs
Frequency: 2.4 GHz
Distance: 100m+
Channels: 4 channels
Groups: 3 groups – A, B, C
Batteries: 2 x AA batteries (TCU and Receiver), 5V DC on receiver (external power port)
Max sync speed: 1/8000 sec*
Output: Hot shoe, 3.5 mm port (receiver)
Input: USB port (transmitter and receiver)
Attachment: 1/4 tripod lug, cold shoe (Receiver)
Input voltage: 2.4-3.2V
Flash port voltage handling: 6V (transmitter) ?300V(receiver)
Body dimensions: 94(L) x 66(W) x 35(H) mm, (transmitter), 90(L) x 45(W) x 40(H) mm (receiver)
Antenna: built-in PCB antenna
Weight: 105g (transmitter), 66g (receiver) – without batteries
Operating temperature: -15—65?
Storage temperature: -30—85?
Compatibility
Nikon Digital Cameras and Flashes. Some third party TTL flashes may function with the Phottix Odin. Due to the vast number of third party alternative Phottix will not test, support or troubleshoot third party flashes.
Flashes: Nikon SB-400, SB-600, SB-700, SB-800, SB-900, SB-910
Cameras: D70 and D70s not compatible.
